Bộ Thu Quang FTTH WDM FWR-8610RW

Mô tả

FTTH/FTTP WDM Mini Node
Nhà sản xuất

Fullwell
Giá

Vui lòng liên hệ
Số lượng

Xem địa chỉ mua hàng

Bộ Thu Quang FTTH WDM FWR-8610RW

Mô tả Sản phẩm
Thông số kỹ thuật
Ứng dụng
Download (file PDF)
Ý kiến khách hàng

Thêm vào giỏ

Mô tả Sản phẩm
Thông số kỹ thuật
Ứng dụng
Download (file PDF)
Ý kiến khách hàng

Mô tả Sản phẩm

Bộ Thu Quang FTTH WDM FWR-8610RW

Fiber to the home ( FTTH ) broadband access is the ultimate development goal, FWR-8610RW optical receiver is the target terminal products for this goal.

FWR-8610RW device adopts technology of high isolation WDM in order to separate CATV and ONU signal.

Further more, it also adopts low optical power receiving and RF-AGC control technique, which could achieve the requirement of ≤-10dBm CATV receiving for FTTH. The optical power receiving monitoring indicator LED ( ≥-15dBm) is provided on the pane and it supports RF outputs constantly, convenience of customers use, which is the ideal receiver equipment for FTTH.

FEATURES

Power Input

Power in：FWR-8610RW is the external power supply input port, First should be the DC+5 V external voltage stabilizer output line connected to the device POWER IN,than put DC+5V external mano-stat insert 100/240 V, DC5V Face posted power light, show power part is regularly working.

Optical Fiber Input

Optical in: FWR-8610RW is input interface of optical signal,in optical access should clean APC TOP by alcohol, than align adapter sunken mouth, fiber mouth march link;when optical signal accesses (≥-15dBm) then lights on in panel, which shows optical part is regularly working;lights will be changed by receive power as yellow (>+2dBm), green (+2～-15dBm) and red (<-15dBm). ONU is 1490/1310nm connection interface, please do not take off the cover before you use.

Install Test Matter Need Attention

1．FWR-8610RW device is indoor type structure, Not to be used in place of harassment by the rain; Packed in the box of the indoor appropriate space, For cooling; The output of the cable shielding network must be grounded, Grounding resistance should be less than 4 Ω, The local power supply for electrical shell has to be grounded, Above ground resistance.

2．Tail fiber input and output cable has to be reserved certain use, FWR-8610RW device is with SC/APC, PON link with SC/UPC (or SC/APC).

Bộ Thu Quang FTTH WDM FWR-8610RW

2018_New_Chart_FTTH-GPON

bo-thu-quang-ftth-wdm-fwr-8610rw ftth_option_system

FWR-8610RW-0 FWR-8610RW-1

FWR-8610RW-2 FWR-8610RW-3

Thông số kỹ thuật

Item		Unit	Performance Parameter
Optical characteristic	Input wavelength	(nm)	1310,1490,1550
	Output wavelength	(nm)	1310,1490
	Operation wavelength	(nm)	1540～1560
	Channel separation	(dB)	≥40（1310/1490nm and 1550nm )
	Response	(A/W)	≥0.9
	Receive power range	(dBm)	+2～-15
	Reflection loss	(dB)	≥55
	Fiber linker	/	SC/APC
	PON linker	/	SC/UPC(or SC/APC)
RF characteristic	Bandwidth/flatness	MHz/dB	47-1000/≤±1
	Output level	dBuv	AGC: 82±1/(-2～--10dBm)
	Reflection loss	dB	≥14（75Ω characteristic impedance）
	RF output interface	/	1 way output (or two way output)
	CNR/MER	dB	≥44/34(PAL-D 60CH,OMI3.8%,-9dBm)
	CTB/CSO/HUM	dB	≥65/≥60/≥60(-1dBm receive)
Other requirement	Power supply/consumption	V/W	External AC100～240V→DC5/5
	Working/storage temperature	℃	-35～50/-40～75(humidity 5～90%)
	Size	mm	95×92×23
