Bộ thu quang trong nhà không có WDM vỏ hợp kim SB-OR16

Item

Unit

Paramter

Remark

Input Wavelength (nm)

(nm)

1100~1600&1550

Operating Wavelength

(nm)

1550 ± 20

Optical input range

(dBm)

-10 ~ -2

Output return loss

(dB)

≥45

Bandwidth (MHz)

MHz

47~862&1000MHz

Flatness (dB)

dB

±1

RF output level

(dBuv)

≥ 20 dBmV per channel, with optical input: -7 ~ -2 dBm (Wavelength 1550 nm)

Output level adjust

(dB)

0 ~ -15

Flatness

(dB)

≤ ± 0.75

Output return loss

(dB)

≥14

Output impendance

(Ω)

75

RF output connector

At least 1 output port, F female type

CNR (dB)

dB

CNR ≥ 50 dB (0 dBm optical input)

or CNR ≥ 49 dB (-1 dBm optical input)

or CNR ≥ 48 dB (-2 dBm optical input)

CTB (dB)

dB

≥65

CSO (dB)

dB

≥62

Power supply (V)

V

AC110V or AC220V

or customized or as request

Other : - Using the external AC/DC adapter, switching mode power supply, with AC input: 100-240 VAC, 50/60Hz, or larger

- Follow the latest SCTV technical standards of external power supplies for end devices or meet at least the following requirements:

Electrolytic capacitor for output with withstand voltage must be at least 1.5 times of output voltage

DC output power: be at least 1.5 times of actual power consumption of respective end device

Output ripple: ≤ ±1.5%

International standard of efficiency, level V

Power consumption

W

≤3

Operating temperature

(℃)

-20~+60

Dimension

mm

105*67*24
